A CAD-to-Walls tool imports AutoCAD® files and provides mapping for layers so you can quickly see the model in 3D. Quickly manipulate objects with multiple copy, align, reflect and replicate at specific intervals. An extensive 3D Library of architectural objects and tools make it easy to detail and accessorize your designs so that styles, finishes and other product-specific design details can be accurately rendered.Ĭhief Architect has a powerful CAD software engine that includes tools for lines, polylines, splines, arcs and solids to produce objects that range from custom entry columns to a deck ledger detail. Advanced rendering provides both Photo Realistic and Artistic styles such as Line Drawing and Watercolor. With Chief Architect, you can design in any view for seamless and simultaneous editing between 2D & 3D.
Chief Architect partners with specific manufacturers (cabinets, appliances, doors, windows, countertops and flooring) so that styles, finishes and other product-specific design details can be accurately drawn and rendered.Īs you draw walls, the program automatically creates a 3D model and supports full 3D editing. Automatic and Manual Building tools allow you to create a variety of Roof styles, Stairs, Framing - both stick and truss, Schedules and Materials Lists for Cut, Buy and Estimating, Dimensioning, Cross-Sections, Elevations and CAD tools.Ĭhief Architect uses smart design objects, such as cabinets, to quickly and easily create various styles, shapes and sizes. Use powerful building and drafting tools to quickly create plans according to standard building practices and make the design process efficient and productive. As you draw walls and place smart architectural objects like doors and windows, the program creates a 3D model, generates a Materials List, and with the use of powerful building tools, helps produce Construction Documents with Site Plans, Framing Plans, Section Details, and Elevations. Professional Home Design Softwareįor all aspects of residential and light commercial design.
It is also possible to perform a manual nesting using a bright laser projector (to nest irregularly shaped materials like scraps of sheets or leather). Patterns imported from CALIGOLA or even from other CAD systems (in dxf exchange format) are automatically nested. Category People & Blogs Show more Show less. Export models to Caligola NP module that, without the need for CAD software, you can cut or print on any HPGL compatible plotter.
